Small Set of Wheat Flour Mill

6FZD-35/40 Style Wheat Flour Mill

Advantage:
no groundhole, lifting the wheat, receiving the bran and flour on the ground, operating, maintaining and operating is easy, which can process the wheat auto matically and reduce the intensity of labour.


6FZD-35/40 Style Flour Milling Machine	6 FTY-10 Style Small Set of Flour Mill

Main Technical Data

style	output(Kg/h) process the wheat	power (kw)	lour quality	LXWXH(mm)	container of 20 feet
6FZD-35	300-400	9.7	confirm with the stipulation of GB-1355-86<Wheat flour>	750x650x750 2200x850x1500	1/6
6FZD-40	350-450	13.2	confirm with the stipulation of GB-1355-86<Wheat flour>	1050x1000x900 2400x250x150	1/6

6FTY-10 Style Small Set of Flour Mill

The main equipment:

No	Name of equipment	Specification	Number
1	flour-milling machine	6FY-35	two sets
2	Fan	6-23NO-5C	one set
3	Fan	8-18NO-4A	one set
4	reel separator	30 style	four sets
5	stoner	QS-40	one set
6	scourer	6NF-90	two set
7	air-lock	GFY-150	four sets
8	sliding separator	30 style	one set
9	auger	150x1000	one set
10	beater	20	one set

Advantage:
6FTY-10 small-scale unit, low investment and high efficiency, is a small complete set of equipment which can produce continuously. It is the epitome of the big unit and the design is principle,operation is simple, repairment is easy and cover little area. The main feature is:
1/ The flour can be adjusted according to the market's requirment, F1 flour, F2 flour and standard flour can be produced.
2/ The covering area: LxWxH=6.6x3.8x3.5(m)
3/ Power consumption low the state standard, the total power is: 26.5KW.
4/ The tempering tank includes two parts, the size of each tank is: LxWxH=0.9x1.5x1.5(m)
